Features
- Simultaneous I/O up to 2 inputs/2 outputs
- 2 mic/instrument/line inputs with XMAX-L mic preamps
- 2 balanced ¼-inch TRS main outputs to connect professional studio monitors
- High-power headphone output
- MIDI In/Out
- Mixer knob for low-latency direct input monitoring
- Front-panel level controls for main outputs
- 4 ladder-style LED level meters (2 input, 2 main output)
- 24-bit resolution, 44.1, 48, 88.2, 96, 176.4 and 192 kHz sampling rates
- USB-C to USB-C and USB-C to USB-A cables included for compatibility with most computers
- Includes Studio One Artist®, Studio Magic Software Suite, and Ableton® Live Lite
World-Class Recording Software Included.
The Studio 24c works with virtually all macOS, Windows, iOS and iPadOS audio-recording software and comes with a license for PreSonus®’ Studio One® Artist for a complete recording solution. Studio One is easy to learn and enables you to compose, record, and produce without getting distracted by the tools.
Make Your Own Magic.
Expand your Studio One® experience with the Studio Magic Suite of software. Studio Magic includes tutorials from Melodics, sound libraries from Ghost Hack, 7 virtual instruments, and 9 effects plug-ins in VST, AU and AAX formats to use in Studio One Artist or your DAW of choice, with a retail value of over $1,000 (US).
Electronics
-
Voltage : USB Bus Powered
-
Inputs : Two – Combo Mic/Instrument/Line Inputs (XLR Female Balanced, 1/4″ TS Female Unbalanced (Inst) or TRS Female Balance (Line))
-
Jack : 1/4″ Stereo
-
Line Out : Two – 1/4″ Balanced (Left and Right)
Miscellaneous
-
Connection Type : USB-C Cable
-
MIDI I/O : Dual 5-Pin Female DIN
Microphone Preamp
-
Total Harmonic Distortion : 0.004% (1 kHz, -1 dBFS, Minimum Gain)
-
Gain Control Range : 50 dB
-
Maximum Input Level : +10 dBu (±0.5 dBu, Minimum Gain)
-
Phantom Power : +48 VDC (10 mA Total)
-
Frequency Response : 20 Hz – 20 kHz (±0.3 dBu, Unity Gain, Unweighted)
-
Input Impedance : 1.4 kΩ
-
Dynamic Range : 106 dB (A-Weighted, Minimum Gain)
-
Equivalent Input Noise : -126 dBu (A-Weighted, 150Ω, Maximum Gain)
Headphone Outputs
-
Maximum Output : 47 mW/Channel @56Ω
-
Frequency Response : 20 Hz – 20 kHz (±0.5 dBu, Unity Gain, Unweighted)
-
Dynamic Range : 83 dB (A-Weighted, 56Ω Load)
-
Total Harmonic Distortion : 0.01% (1 kHz, 0 dBFS, Loaded)
-
Impedance Working Range : 32Ω to 300Ω
Digital Audio
-
Dynamic Range : 108 dB
-
Bit Depth : 24 Bit
-
Supported Sample Rates : 44.1, 48, 88.2, 96, 176.4, or 192 kHz (kHz)
