Features

  • Simultaneous I/O up to 18 inputs/8 outputs (8×6 at 192 kHz)
  • 2 mic/instrument/line inputs with XMAX Class A mic preamps
  • 2 mic/line inputs with XMAX Class A mic preamps
  • 4 balanced ¼-inch TRS direct-to-ADC line inputs
  • 8 channels of ADAT Optical input (4 channels at 96 kHz)
  • 2 balanced ¼-inch TRS main outputs and 2 balanced ¼-inch TRS line outputs for monitor mixing all DC coupled for sending control voltages
  • High-power headphone output
  • Stereo S/PDIF digital I/O and MIDI In/Out
  • 18×6 onboard DSP monitor mixer
  • Front-panel mute and level controls for main outputs
  • 6 ladder-style 8-LED level meters (4 input, 2 main output)
  • 24-bit resolution, 44.1, 48, 88.2, 96, 176.4 and 192 kHz sampling rates
  • USB-C to USB-C and USB-C to USB-A cables included for compatibility with most computers
  • Includes Studio One Artist®, Studio Magic Software Suite, and Ableton® Live Lite

World-Class Recording Software Included.

The Studio 1810c works with virtually all macOS, Windows, iOS and iPadOS audio-recording software and comes with a license for PreSonus®’ Studio One® Artist for a complete recording solution. Studio One is easy to learn and enables you to compose, record, and produce without getting distracted by the tools.

World-class recording software included.

Make Your Own Magic.

Expand your Studio One® experience with the Studio Magic Suite of software. Studio Magic includes tutorials from Melodics, sound libraries from Ghost Hack, 7 virtual instruments, and 9 effects plug-ins in VST, AU and AAX formats to use in Studio One Artist or your DAW of choice, with a retail value of over $1,000 (US).

Make your own magic.

Electronics

  • Voltage : 120V
  • Inputs : Eight – Four Combo Mic/Instrument/Line Inputs (XLR Female Balanced, 1/4″ TS Female Unbalanced (Inst), Four 1/4″ Line
  • Headphone Jack : 1/4″ TRS Active Stereo

Miscellaneous

  • MIDI I/O : Dual 5-Pin Female DIN

Microphone Preamp

  • Total Harmonic Distortion : 0.005% (1 kHz, 0dBu, Unity Gain)
  • Gain Control Range : 80 dB
  • Maximum Input Level : +16 dBu, Minimum Gain
  • Phantom Power : 48V (>10 mA per Channel)
  • Frequency Response : 20 Hz – 20 kHz (Unity Gain)
  • Input Impedance : 1.4 kΩ
  • Dynamic Range : 110 dB (A-Weighted, Minimum Gain)
  • Equivalent Input Noise : -128 dBu (A-Weighted, 20 kHz BW, Rs=150Ω, Maximum Gain)

Line Inputs

  • Maximum Level : +21 dBu (balanced, Minimum Gain)
  • Line Inputs Gain Range : 40 dB
  • Line Inputs Frequency Response : 20 Hz – 20 kHz (Unity Gain)
  • Line Inputs Dynamic Range : 112 dB (A-Weighted, Minimum Gain)
  • Line Inputs Total Harmonic Distortion : 0.005% (1 kHz, +18 dBu, Minimum Gain)
  • Line Inputs Impedance : 10 kΩ

Main And Line Outputs

  • Main And Line Outputs Maximum Level : +18 dBu, Balanced
  • Main And Line Outputs Frequency Response : 20 Hz – 20 kHz (Unity Gain)
  • Main And Line Outputs Total Harmonic Distortion : 0.004% (1 kHz, -1 dBFS, Unity Gain)
  • Main And Line Outputs Dynamic Range : 108 dB (A-Weighted, Unity Gain)

Headphone Outputs

  • Maximum Output : 150 mW/Channel (60Ω Load)
  • Frequency Response : 20 Hz – 20 kHz (Unity Gain)
  • Dynamic Range : 103 dB (A-weighted, 1 kHz, Unity Gain)
  • Total Harmonic Distortion : 0.250% (1 kHz, 150 mW, Unity Gain)
  • Impedance Working Range : 32Ω to 600Ω

Digital Audio

  • Supported Sample Rates : 44.1, 48, 88.2, 96, 176.4, 192 kHz (kHz)
