Features
- Professional USB-C®-compatible condenser microphone:ideal for vocals and acoustic instrument recording, live streaming, and more
- Professional sound made easy: Professionally crafted Presets make you and your guitar sound pro with a single click. Create your own custom presets to share, save, or produce on the go.
- Selectable pickup patterns:
- Cardioid for single-source applications
- Omnidirectional to pick up the entire room
- Figure-8, perfect for duos and collaboration
- Customizable mixes: Integrated mixer with two dedicated loopback audio channels to add backing tracks. Perform live online with backing tracks while recording the entire show!
- Onboard processing: Effects processing lets you polish your sound with reverb, compression, EQ, and fantastic Voice FX — all built into Revelator, and remotely-controllable from your compatible mobile device
- Recording Software included: Complete recording solution featuring Studio One Artist DAW recording software and Studio Magic software bundle including music tutorials, tons of sound samples and virtual instruments; plus Ableton Live Lite
- Built-in headphone amplifierwith zero-latency monitoring let you listen in real-time
- Bus-Powered: Revelator is powered by your connected USB-C device so no need for an additional power supply. It works great with both Apple and Android devices.
Get Recording Right Away.
Revelator comes with a complete suite of professional software to take your sound to the next level. Studio One® Artist features lightning-fast drag-and-drop workflow, a complete suite of plug-ins, and the professional mixing and production tools that made Studio One so beloved.
Analog Classics Under The Hood.
Revelator is the first USB microphone to provide State Space-modeled analog processing onboard with the same Fat Channel gate, compressor, and EQ our StudioLive Series III mixers offer. Like what you hear? All processing can be printed to your recording, or just used for your monitor mix, you decide.
Ready To Go Live When You Are.
Revelator’s presets are stored on the mic, so you can take your sound with you. Connect directly to your iPad Pro, or grab your Camera Connection Kit and connect your Revelator to your Lightning- or USB-C-equipped iPhone or iPad. Only Revelator brings studio-quality sound to Facebook Live, IGTV, or anywhere else you stream from your mobile device.
Electronics
-
Jack : 1/8″ TRS Active Stereo
-
Effects : PreSonus Fat Channel: High Pass Filter, Noise Gate, 3 Compressor models, 3 EQ models and Limiter. Voice Effects: Comb Filter, Delay, Doubler, Ring Modulator, Vocoder and Reverb
Miscellaneous
-
Connection Type : USB 2.0 Bus-Powered
Microphone
-
Polar Pattern : Cardioid, Bidirectional (Figure 8), Omnidirectional
-
Type : Mono Condenser
-
Sensitivity : 1 mV/Pa
-
Maximum SPL : 110 dB <3% THD
-
Frequency Response : 20 Hz to 20 kHz
Headphone Outputs
-
Maximum Output : 22.6 mW (16Ω)
-
Frequency Response : 20 Hz to 20 kHz
-
Dynamic Range : 77.5 dB
-
Total Harmonic Distortion : 0.01%
-
Impedance Working Range : 16Ω
Digital Audio
-
Bit Depth : 24-bit
-
Supported Sample Rates : 44.1, 48, 88.2, and 96 kHz (Note: 44.1 and 48 kHz only on macOS while in Multi Mode)
Monitors
-
Audio Controls : Direct Monitor, Mic Gain, Headphone Level, Mute, Preset Select
