Features
- 25.5″ scale length
- Basswood body
- Bolt-on caramelized maple neck with graphite reinforcement, scarf joint and oiled back finish
- 20″ radius caramelized maple fingerboard with rolled edges, 24 jumbo frets, offset white dot inlays and luminous side dots
- Heel-mount truss rod adjustment wheel
- Uncovered direct mount Jackson MM1 pickups
- Five-way blade switch, single volume control and single tone control with push/pull select feature
- Jackson HT6 string-through-body hardtail bridge
- Jackson sealed die-cast locking tuners
- Horizon Devices Strings – Progressive Tension Standard 6
- Available in Matte Blue Frost or Satin Black with a matching reverse Jackson 3×3 AT-1 headstock and black hardware
UNCOVERED DIRECT MOUNT MM1 HUMBUCKING PICKUPS
Mansoor’s pursuit of perfect tone led to the custom-voiced MM1 pickups. They feature balanced tone and dynamic sound that respond well to aggressive pick attacks but remain clear to let every chord ring through.
CARAMELIZED MAPLE NECK AND FINGERBOARD
The caramelized maple neck and caramelized maple fingerboard have been roasted for increased stability, exquisite style with gorgeous grain definition and smoother playability for crystal clear, bright tones.
PICKUP SWITCHING
5-Position Blade: Position
1. Full Bridge Pickup, Position
2. Two Inside Coils, Position
3. Both Full Humbucking Pickups, Position
4. Two Outer Coils, Position
5. Full Neck Pickup
BRIDGE
Jackson® HT6 6-String Hardtail with String-Through-Body
| Jackson Pro Series Misha Mansoor Juggernaut HT6 | |
| COLOR: MATTE BLUE FROST,SATIN BLACK | |
| Body: | Basswood, Juggernaut Body Shape |
| Satin Finish | |
| Neck: | 1-Piece Bolt-On Caramelized Maple Speed Neck |
| Graphite Reinforcement and Scarf Joint, | |
| Caramelized Maple Fingerboard, 20″ Radius, Offset Dots | |
| Inlays, Oiled Neck Finish | |
| Frets: | 24 Jumbo |
| Pickups: | Jackson® Uncovered MM1 (Neck), |
| Jackson® Uncovered MM1 (Bridge) | |
| Controls: | Volume, Tone (with Push/Pull Select Feature) |
| 5-Position Blade: Position | |
| 1. Full Bridge Pickup Position | |
| 2. Two Inside Coils, Position | |
| 3. Both Full Humbucking Pickups, Position | |
| 4. Two Outer Coils, Position | |
| 5. Full Neck Pickup | |
| Hardware: | Jackson® HT6 6-String Hardtail with String- |
| Through-Body Bridge, Jackson® Die-Cast | |
| Locking Tuners, Black | |
| Case: | N/A |
